Genie G Ultrapure & EDI Lab Water System
Genie G produces ultr apur e w ate r ( Type I w ater) a nd EDI w ate r ( Type I I w ater) f rom tap water directly. Quality of ultrapure water and EDI water meet or exceed ASTM, CLSI, CAP, and ISO Type I water and Type II water standards, respectively. The system is CE/RoHS certified. RephiLe
provides full documents support to meet user’s GMP, GSP, GAP, GCP, GLP requirements. Catalog No.: RG0G005T0, RG0G010T0, RG0G015T0
Spesifikasi
| Tap water | Municipal water, Conductivity < 2000 μS/cm (1000 ppm) |
| Operating temperature | 5 – 35 ℃ |
| Feed water pressure | 1 – 6 bar (15 – 90 psi) |
Water Flow Rate
| EDI water production rate (@ 25℃) | 5, 10, 15 L/hr |
| EDI water dispensing rate | Up to 2.0 L/min |
| Ultrapure water dispensing rate | Up to 2.0 L/min |
Product Water Quality
| RO rejection | 97 to 98% ionic rejection (new RO cartridge) > 99% organic rejection > 99% particulates & bacteria rejection |
| EDI water resistivity (@ 25℃) | > 5 MΩ·cm (typically 10 – 16 MΩ·cm) |
| EDI water TOC* | < 30 ppb |
| Ultrapure water resistivity (@ 25℃) | 18.2 MΩ·cm |
| Ultrapure water TOC* | < 2 ppb |
| Particles in ultrapure water ( > 0.2 μm) | No particles (with a 0.2 μm final filter or RephiBio filter) |
| Microorganisms in ultrapure water | < 0.01 cfu/ml (with a 0.2 μm final filter or RephiBio filter) |
| Pyrogens in ultrapure water | < 0.001 Eu/ml (with a RephiBio filter) |
| RNase in ultrapure water | < 0.5 pg/ml (with a RephiBio filter) |
| DNase in ultrapure water | <10 pg/ml (with a RephiBio filter) |
Dimensions
| Main system dimensions Width × depth × height |
32 × 44 × 54 cm (12.6 × 17.3 × 21.3 in) |
| Dispenser dimensions Width × depth × height |
21 × 29 × 61 cm (8.3 × 11.4 × 24.0 in) |
| Weight | 20 kg |
| Input Voltage | 110 – 240 VAC |
| Operating Voltage | 24 VDC |
| Main system power | < 200 W |
